HR-25℃~200℃ cooling heating circulator

Only control of reactor temperature

Cooling Heating Circulators Products

• Heating Power2.5kW~15kW
• Cooling capacity1kW~15kW
• Power range4kW~21kW
• Medium accuracy±0.5℃
• RefrigerantR404A/R507C
• Weight150KG~320KG
• Details

cooling heating circulatorcooling heating systemreactor chiller

MAIL INQUIRY

WHATSAPP INQUIRY

● Working temperatures from -45°C to +250°C, cooling and heating
● With 2pcs of LED display controller, can show the setting temperature & actual value, and alarm value for overtemperature.
● Efficient fast, simple topping up liquid.
● Maximum process stability and reproducibility
● Ensure fast cooling at high temperature and can acheive 200℃ ~ -20℃ temperature control continuously.
● The cycle system is closed, there is no oil mist and water vapor happend, so as to assure the lab safety and heat transfer fluid lifetime.
● Use copeland brand compressor, circulation pump, stable performance and reliable quality.
● Self-diagnosis function; freezer overload protection; high-pressure switch, overload relay, thermal protection device, liquid low level protection, high temperature protection and temperature fault protection.

The whole liquid circulation is a closed system. There is no absorption of water vapor at low temperature and no oil mist at high temperature. The heat transfer oil can work at a wide temperature. There is no solenoid valve in the whole circulation system.
